Part No

Nose Dia.

Nose Length

Shoulder Dia

5007

6.35

11.70

Cap

5016

8.00

4.90

9.50

5018

5.94

3.25

7.94

5019

7.87

11.20

11.20

Part No

O/All Length

Thread
Length

Dia or A/F

Thread

Conduit
Socket

9006

38

28

7.94 A/F

1/4” bsf

6.60

9028

38

28

7.94 A/F

M6 x 1

6.60

9028/1

38

21

7.94 A/F

M6 x  1

6.60

9032

38

28

7.94 A/F

1/4” unf

6.60

9049/B5

57

31

7.94 Dia

M6 x 1

5.60

9024

Midway  Adjuster to Suit 9006

Part No

Dia

Length

7026/S

6.35

12.70

7027/S

7.92

12.70

7028/S

9.53

12.70

7049/S

7.92

8.89

Part  No

Dia

7016

4.69

7017

6.29

7132

7.45

Part No

Dia

Length

7022

6.35

6.35

Part No

Dia.

Length

7009

6.35

6.35

7013

9.53

9.53

7018

6.35

9.53

7056

6.00

10.00

7060

9.53

12.70

Part No

Head Dia

O/all Length

Shank Dia

Shank Length

7005

6.35

9.40

3.96

6.35

7008

5.54

7.87

3.45

4.83

7021

7.92

12.70

4.75

8.64

7032

4.75

7.87

3.18

5.59
